| Genset | Genset Model | PLD-100GF | PLD-112GF |
| Rated Power (kW/kVA) | 100/125 | 112/140 | |
| Standby Power (kW/kVA) | 110/137.5 | 123.2/154 | |
| Rated Current (A) | 180 | 202 | |
| Manufacturer | Pulita Energy | ||
| Diesel Engine | Main Engine-Body Make | Cummins | Weichai |
| Diesel Engine Model | 6BTA5.9-G2 | WP6D132E200 | |
| Rated Power (kW) | 106 | 120 | |
| Type | Four Stroke, Water Cooling, Direct injection, 24V DC Starting | ||
| Displacement (L) | 5.9 | 6.75 | |
| Bore× Stock (mm) | 102*120 | 105*130 | |
| Air Intake Way | Turbo-charging | Turbo-charging | |
| Rated Speed (r/min) | 1500/1800 (50/60Hz) | ||
| Fuel consumption(L/Kw·h) | 0.21 | ||
| Alternator | Brand/Model | Faraday | |
| FD3C-4 | FD3DS-4 | ||
| Frequency (Hz) | 50/60 | ||
| Excitation Method | Self-excited, Brushless, AVR | ||
| Phase/Connection | 3 Phase 4 Wire, Y-connection, 0.8 Power Factor (Cosφ) | ||
| Protection Level/Insulation Class | IP23/H | ||
| Control System | The standard control panel is with functions including manual keys, alarms, protections, auto start and shut down, showing running parameters in LCD Display by DEIF SGC420 Controller. | ||
| Options | Special requirements for Container, ATS, Synchronizing Parallel panels are available for options. | ||
| Dimension (for Open Genset, mm) | 2400*950*1510 | 2400*950*1510 | |
| Weight (KG) | 1500 | 1500 | |
